PIEZO ELECTRIC ALARM WITH INTERNAL CIRCUITRY

PIEZO ELECTRIC ALARM WITH INTERNAL CIRCUITRY
  • Product: PIEZO ELECTRIC ALARM WITH INTERNAL CIRCUITRY
  • Description: Panel Mount with Circuit
  • Part Number: BRP4222T-24-C
SPECIFICATIONS
FRAME DEPTH 20.5 mm
FRAME DIAMETER 42.0 mm
MAX CURRENT 15 mA
MOUNTING DIMENSIONS 10.0 mm
OPERATING TEMPERATURE -20 TO +60°C
OPERATING VOLTAGE 1 ~ 28 vdc
RATED VOLTAGE 24 vdc
RESONANT FREQUENCY 2900 ± 500 Hz
ROHS COMPLAINT YES
SOUND LEVEL OUTPUT 85dB @ 30 cm
TERMINAL TYPE 2 Plates
TONE MODE CONTINUOUS

To process your Quote /Sample Request click the "VIEW CART:"" top right of page

DIMENSIONS
